1873 Gripper Chain Laydown Conveyors Bottle Sterilizer Conveyor, PET Bottle Inverted Sterilizer

1873 Gripper Chain Laydown Conveyors Bottle Sterilizer Conveyor, Bottle Sterilizing Laydown Conveyor, 1873 D 41LF 1873 G4 Inverted Gripper Chain Conveyor, 41LF 1873G4PXK, used for Side Grip Inverters, Vertical Conveyor Elevators Lowerators
1873 Gripper Chain Laydown Conveyors Bottle Sterilizer Conveyor

1873 G4 Gripper Chains Snap-on Chains Conveyor Rinsers Elevators

Material: POM Acetal Brown Plate, Rubber Top Gripper, Carbon or Stainless Steel Roller Base Chain # 12A 60
Application: Side flexing gripper conveyor for PET bottles, elevating bottling and turnkey bottle inverter, bottle jug.
Max Speed: 80m/min lubricated, 50m/min dry
Max Length: 30m (Carbon Steel), 24m (Stainless Steel)
Packing: Roller Chain length 1.524 m = 80 pitch = 5 ft
One Top Plate through Two Pieces Base Roller Chain
Snap-on Finger Grip 1873-G4 Gripper Chains

1873-G4 Gripper Chains

Snap-on Rubber Gripper Top 1873 G4 Gripper Chains Bottle Inverters

- 1873-G4 Finger Gripper Chains Supplied with Molded Rubber Inserts, Base Roller Chains in CS Carbon Steel #60 12A, Stainless Steel Roller Chain ANSI 60 12A, used for Side Grip, Vertical Conveyor of Cans or Water Bottles Jugs, Diary Milk Jug Bottle Neck Sterilisation
- Base Chain Pitch 3/4" 19.05 (Single Strand Roller Base Chains), Plate Chain width 82,5mm (3.25”) and 93,2mm, Rubber Gripper & Roller Base Chain Snap-on Plate Chain

Chain Code CS Chain Code SS Width(mm) Rubber(mm) Weight(kg/m)
1873 G4-K325 1873SS G4-K325 82.5 75 3.5
1873 G4-K375 1873SS G4-K375 93.2 84 4.7

More Detailed Specs. Information, Please Refer to.: 1873 G4 Gripper Chains
* 1873 Steel TAB Gripper Chains Supplied with Molded Rubber Inserts, Suitable for Radius Conveyor, Beverage Applications, Bottle Inverters, Rinsers Elevators Lowerators Horizontal Transfers, Vertical Side Grip Conveyors
* Other series gripper retainers on steel or stainless steel base chain & plastic base plate:
1873 Tab Gripper Chain, 1873 D Style Gripper Chain, 1873 Side Grip Chain with Finger Jaw Gripper, 1873 G4 Gripper Chain, 1873 GS Gripper Chain, 1873 GV Gripper Chain
Gripper rubbers are available in black or white NBR, EPDM, Neoprene

1873 Bottle Gripper Chain Inverters Elevators Conveyor Rubber Top

1873 Bottle Gripper Chain Inverters Elevators Conveyor Rubber Top
1873 Bottle Gripper Chain Conveyor Rubber Top Grip
