LBP 821 882 Roller Top Chains Low Back Pressure Conveyor Chain

Material: POM Acetal (LF Brown Low Friction Chain, Rollers Blue), Stainless Steel Pin Rod
Applications: Beverage Packaging, Case or Crate Products Accumulation Damage Reduction Conveyor, Shrink Wrapped PET Conveying

* Low Back Pressure LBP 821 882 Roller Top Chains are slat chains with small rollers on top for low-pressure case or crate accumulation, offering low coefficient of friction, improving product stability and lessens the opportunity for packaging damage

LBP 821 882 Roller Top Chains Low Back Pressure

Chain Code Width W(mm) Roller Width(mm) Backflex Rad. Weight(kg/m)
LBP 821-K750 190.5 174.5 255 3.45
LBP 821-K1000 254.0 238.0 255 4.80
LBP 821-K1200 304.8 288.8 255 5.65
LBP882TAB-K375 95.2 79.0 101 3.7
LBP882TAB-K750 190.5 174.0 101 5.2
LBP882TAB-K1000 254.0 238.0 101 7.2
LBP882TAB-K1200 304.8 289.0 101 8.5

LBP 882 Roller Top Side-flex Radius Chains

Material: POM Acetal (LF Brown Low Friction, Rollers Blue), Stainless Steel Pin Rod
Main Application: Beverage Packaging, Products accumulation damage reduction, Shrink wrapped PET conveying
Max Conveyor Length: 12m, Work Temp.: -40°C to 90°C
Packing: 3.048m, 10ft or 80 links/box, 26pcs/meter

LBP 882-TAB

LBP 882 TAB Roller Top Chains Radius

Material: POM Acetal (LF Brown Low Friction, Rollers Blue), Stainless Steel Pin Rod
Main Application: Beverage Packaging, Products accumulation damage reduction, Shrink wrapped PET conveying
Max Conveyor Length: 12m, Work Temp.: -40°C to 90°C
Packing: 3.048m, 10ft or 80 links/box, 26pcs/meter

LBP 882 PRR TAB

Chain Code Width W(mm) Roller Width(mm) Backflex Rad. Weight(kg/m)
LBP882TAB-K750 190.5 174.0 101 5.2
LBP882TAB-K1000 254.0 238.0 101 7.2
LBP882TAB-K1200 304.8 289.0 101 8.5

For more specifications, please refer to: LBP Roller Top Chains
